Product Description

Boost your sodium silicate (water glass) production with our high-quality stainless steel reactors, designed for corrosion resistance, high-temperature stability, and long-lasting performance.

Customized part
1. Volume: 100 ~ 10000L
2. Material: SS304 , SS316 ; Carbon steel , Lined PTFE
3. Agitator: anchor , frame , paddle , multifunction type (frame, dispersing mixer, emulsify mixer) etc.
4. Type: single layer, double layer (with jacket to heating or cooling), external coil-pipe type
5. Heating method: electric heating, steam heating, circulation oil heating, infrared heating etc.

Model	100L	300L	500L	1000L	2000L	3000L	5000L
Mixing Motor Power	1.1KW	2.2KW	2.2KW	4KW	5.5KW	7.5KW	15KW
Heating Motor Power	12KW	24KW	36KW	48KW	60KW	75KW	90KW
Inner Layer Size (Dmm)	500	800	900	1200	1400	1600	1800
Jacket Size (Dmm)	700	1000	1100	1400	1600	1800	2000
Inner Plate Thickness	5mm	5mm	5mm	6mm	6mm	8mm	8mm
Jacket Plate Thickness	5mm	5mm	5mm	6mm	6mm	8mm	8mm
Material	SS304, SS316L, Carbon Steel; It also can lined PTFE. It can be customized to meet your requirement.
Heating Type	electric heating, steam heating, oil circulation heating etc.
Agitator	anchor, paddle, frame etc.
Sealing Method	packing seal or mechanical seal (vacuum)
Model	We still have more models. (6000l, 8000l, 10000l, 15000l, 20000l, 30000l etc.)

Investing in our High Efficiency Titanium Tube Heat Exchanger,Heat Exchanger,Storage Tank,Reactor means investing in a future-proof solution that delivers superior performance and longevity. Don't miss out on the opportunity to elevate your thermal management capabilities with cutting-edge technology.
